Luminous ECO WATT NEO 850 Square Wave Inverter

(3 review)
Sorry! Delivery not available to this area!
  • Brand : Luminous
  • Inverter Capacity: 800Va
  • Inverter Output: Square Wave
  • Warranty: 24 Months*
  • Support Number of Battery : 1 Battery (12V)
  • Product Model: Eco Watt Neo
  • Output Mode: Inverter-Home UPS
  • Input Protection: Fuse

Delivery not available

SKU: ECO WATT NEO 850

Luminous ECO Watt Neo 850 Square Wave Inverter Description

  • Square Wave
  • 24 Months Warranty
  • Supports Flat, Tubular, SMF & Local Battery
  • 3-Stage Battery Charging

Reference Load Chart

Appliances/Electronics

No. of Appliances used at the time of power cut



A

B

 LED TV 40"

1

2

 LED Bulb 9W

5

5

 LED Tubelight 18W

4

2

 Fans

3

2

 Fridge (250 Litre)

0

0

Total Watt (Consumption)

432 W

391 W

Recommended battery options and Backup Time

Battery

Backup for 432W

Backup for 391W

120Ah Rating

105 Min

120 Min

150Ah Rating

135 Min

160 Min

Consideration

  • Power Watt considered - LED TV 40''- 75W, Fan 1200mm - 80W, Refregerator - 200W, AC 1.5 Tonne - 2000W
  • Recommended running load should be at 75% of peak load
  • Kindly check the rated power consumption of your appliances before selecting the Home UPS

Product Description



  • Square Wave technology
  • Capacity 800VA, Rated Power 672W
  • High charging current even at low input voltage 100V
  • Supports single battery
  • Supports ECO & UPS mode
  • Supports all Battery Types: TUBULAR, FLAT PLATE,SMF & LOCAL
  • Current setting for quick charging of battery
  • 24 Month Warranty

Three Stage Charging

This UPS supports 3-stage smart charging to ensure safe & efficient charging and longer battery life.

Quick Battery Charging

Selectable High charging current for quick battery charging according to battery capacity.

Supports all Battery Types

The UPS supports all types of batteries like flat plate, tubular, VRLA, SMF - gives you the flexibility to choose from a wide range of batteries.

ECO & UPS mode

In UPS Mode, output voltage is kept in range of 180V to 260V - ensuring safety of sensitive appliances such as computers. In Eco Mode, voltage range is extended thereby reducing battery usage.

Warranty Terms

Warranty Summary 24 Months manufactured warranty
Service Type National
Covered in Warranty As per manufacture Guidelines
Not Covered in Warranty Physical Damage

Inverter Technical Details

Recommended Battery Rating 100-220 Ah
Capacity 672 Watt
Output Technology Square Wave
VA Rating 800 Va
Output Voltage 220V -230V
Load Options LED/CFL, TV, Fan, Computer, Printer
Output Frequency 45-55 Hz
Input Voltage 110V - 265V
Solar Power Compatible No.
No. of Batteries Supported (12V) 1 Number
Input Mains Type Single Phase
MCB Protection No.
Supports Battery Type Flat Plate, Tubular & VRLA (SMF)
Easy Bypass Switch No
UPS mode Yes

Dimensions

Width 26.1 cm
Height 27.5 cm
Depth 12.4 cm
Net weight 7.9 Kg

In The Box

Sales Package 1 N Inverter, 1 N Manual

Manufacture Info

Manufacture By Luminous Power Technologies Private Limited
Country of Manufacture India

Delivery & Installation

Days 1-2
