Luminous ECO VOLT+ 1650 / 24Volt Pure Sine Wave Inverter

(3 review)
Sorry! Delivery not available to this area!
  • Brand : Luminous
  • Inverter Capacity: 1500Va
  • Inverter Output: Pure Sine Wave
  • Warranty: 24 Months*
  • Support Number of Battery : 2 Batteries
  • Product Model: ECO VOLT +
  • Output Mode: Inverter-Home UPS
  • Input Protection: Fuse

Delivery not available

SKU: ECO VOLT + 1650

Luminous ECO Volt+ 1650 Sinewave Inverter

  • Pure Sine Wave Output
  • 24 Months Warranty
  • Supports Flat, Tubular, SMF & Local Battery
  • ABCC Technology
  • Overload protection with auto reset
  • High efficiency

Reference Load Chart

Appliances/Electronics

No. of Appliances used at the time of power cut



A

B

 LED TV 40"

2

3

 LED Bulb 9W

10

11

 LED Tubelight 24W

7

4

 Fans

5

4

 Fridge (250 Litre)

1

1

 AC (1.5 Tonne)

0

0

Total Watt (Consumption)

966

916

Recommended battery options and Backup Time

Battery

Backup for 966W

Backup for 916W

120Ah Rating

40 Min

40 Min

150Ah Rating

50 Min

55 Min

Consideration

  • Power Watt considered LED TV 40" 75W. Fan 1200mm - 80W. Refrigerator- 200W
  • Battery time calculated at 75% to 100% of peak load
  • Recommended load should be at 75% to 100% of peak load
  • Kindly check the rated power consumption before selecting the home UPS

Product Description



  • Sine Wave Inverter
  • Capacity – 1500 VA, Rated Power – 1260 W
  • Supports Double battery
  • 24 Month Warranty
  • Safe for sensitive appliances with Sine wave out-put.
  • Three Stage Charging for safe & efficient charging and longer battery life. 4-step battery type selection.
  • Equipped with overload protection with auto reset.
  • Special designed for Indian power conditions with rugged technology design for high performance and longer back-up time.
  • Supports the ECO Mode (180V to 260V) for safety of sensitive appliances & UPS mode (extended voltage range) for reduced battery usage.
  • Noiseless Operations with the help of low harmonic distortion
  • Supports wide battery range, i.e. Flat Plate, Tubular & VRLA (SMF)

Pure Sine Wave output

Delivers pure sine wave output thereby ensuring safety of your appliances. Appliances run without noise and last longer.

Supports all Battery Types

The UPS supports all types of batteries like flat plate, tubular, VRLA, SMF - gives you the flexibility to choose from a wide range of batteries.

ABCC technology

Adaptive Battery charging control system technology (ABCC) ensures faster battery charging and enhances battery life.

ECO & UPS mode

In UPS Mode, output voltage is kept in range of 180V to 260V - ensuring safety of sensitive appliances such as computers. In Eco Mode, voltage range is extended thereby reducing battery usage.

Warranty Terms

Warranty Summary 24 Months manufactured warranty
Service Type National
Covered in Warranty As per manufacture Guidelines
Not Covered in Warranty Physical Damage

Inverter Technical Details

Recommended Battery Rating 100Ah-220 Ah
Capacity 1260 Watt
VA Rating 1500 Va
Output Technology Pure Sine Wave Inverter
Output Voltage 220V -230V
Input Voltage 110V - 265V
Load Options LED/CFL, TV, Fan, Computer, Printer
Output Frequency 45-55 Hz
Solar Power Compatible No.
No. of Batteries Supported (12V) 2 Number
Input Mains Type 3 Phase
MCB Protection Yes
Supports Battery Type Flat Plate, Tubular & VRLA (SMF)
Easy Bypass Switch Yes
UPS mode Yes

Dimensions

Width 26 cm
Height 12 cm
Depth 32 cm
Net weight 13.5 Kg

In The Box

Sales Package 1 N Inverter, 1 N Manual

Manufacture Info

Manufacture By Luminous Power Technologies Private Limited
Country of Manufacture India

Delivery & Installation

Days 1-2
